Features of This Unit
Integrated Housing
The integrated system housing the recording memory in the main camera unit seals in the internal
electronic circuits with a durable structure that does not come into contact with outside air.
Superior Performance
High speed photography requiring advanced techniques can be easily performed.
While remote operation from a PC is possible using the included software, the function of live
image display to a monitor with a simple operation using a dedicated remote control (V-PAD)
makes it possible to perform recording and analysis without using a PC.
Perform continuous recording to the semiconductor memory or via the record trigger input with
confidence that images will not be accidentally lost. Furthermore, various phenomenon may
be captured and recorded by multi-trigger recording (recording of multiple phenomenon by
receiving a plurality of trigger signals), burst recording (recording only during the time that the
trigger signals are active), or by the image trigger function (recording by detecting the change
in intensity in a specific region).
Flexible Image Playback
Slow motion playback of recorded images or repeated playback in a specified range is possible.
Detailed image analysis can be conducted with video output or on a PC.
High-Speed Network Transfer
Recorded images can be digitally saved to a PC through the network, including the data
settings during recording and the trigger timing. 1000BASE-T/100BASE-TX ethernet is used for
high speed transfer, even for large amounts of video data with high resolution/long recordings.
Also, direct saving to a USB compatible external storage media connected to the USB port of
the main camera unit is possible.
Various External Interfaces
Equipped with various external input/output interfaces, including 1000BASE-T/100BASE-TX
ethernet, USB2.0/USB3.0/USB3.0microB, recording start signal input, IRIG-B signal input,
discrete status signal input/output, exposure pulse signal output and recording trigger signal
input. The system is compatible with a wide range of recording conditions.
