Superimposed Information Details
MULTIS(L)
An example of the MULTIS(L) recording method, with the auto segment (block) switch on
LOOP, partitioned into 2 segments and 4 blocks, and performing auto switching to the segment
according to LOOP.
After switching to the ARM mode, it switches to the REC mode upon trigger input. After
(1) recording is done according to the trigger timing, it automatically moves to the next
block and switches to the ARM mode.
Once the recording for all of the blocks is done, it automatically moves to the next
(2)
segment, and switches to the ARM mode.
Once the recording for all of the segments and blocks is done, it moves to the
(3) first segment, and switches to the ARM mode again. (the first memory segment is
overwritten.)
If recording is done, press STOP. The image for the segment being recorded is recorded until
STOP is pressed.
