Adjust the Image Quality of the Video
Set the Luminance Properties (Luminance - NORMAL)
1 Select the play settings tab icon
2 Select inside the Image...tab box
Select the box under Luminance
3
•A popup window is displayed
Select an item from the popup win-
dow
•Select NORMAL
With the normal settings, the image
4 is displayed with the input/output
conversion properties matching the
dynamic range for the camera. The
gain, gamma and knee can be used.
(A 5-11 )
Select the target item in the box to
5 the right under the NORMAL Details
•A popup window is displayed
Select the item in the popup window
6
7
5-10
1
4
3
5
6
