EVENT(L)
An example of the EVENT recording method, with the auto segment switch at LOOP, partitioned
into 4 segments, switching to segments according to LOOP.
After switching to the ARM mode, it switches to the REC mode upon trigger input. If
(1) an external trigger is input before recording ends, it is treated as an event trigger and
recorded.
Recording is done according to the trigger timing. Then it automatically moves to the
(2) next segment and switches to the ARM mode. The event triggers can be recorded to all
segments.
Once the recording for all of the segments is done, it moves to the first segment, and
(3)
switches to the ARM mode again. (the first memory segment is overwritten.)
If recording is done, press STOP. The image for the segment being recorded is recorded until
STOP is pressed.
(00471)H
Superimposed Information Details
9-21
