External Input/Output Signal
TRIG1
Input Signal
(1 of 3 Trigger)
TRIG2
EST1
Input Signal
(2 of 3 EST)
EST2
Input Signal
(3 of 3 ARM) ARM Input
EPO Output
(EPO connec-
t o r / R E M O T E
connector)
Output Signal
ARM Status
Output
FAULT Status
Output
(Note) Factory settings
(00471)H
Select the Setting for the External Input/Output Signals
Polarity
External trigger signals from the TRIG connector
POSI
detected current on (insulating) .
NEGA External trigger signals from the TRIG connector
(Note) detected current off (short circuit).
C R N T O N External trigger signals from the TRIG2 input
(Note) (REMOTE connector) detected current on.
External trigger signals from the TRIG2 input
CRNTOFF
(REMOTE connector) detected current off.
EST signals from the EST connector detected with
POSI
the rising edge.
NEGA EST signals from the EST connector detected with
(Note) the falling edge.
EST signals from the EST2 (REMOTE connector)
POSI
detected with the rising edge.
NEGA EST signals from the EST2 (REMOTE connector)
(Note) detected with the falling edge.
ARM command signals detected with the rising
POSI
edge.
NEGA ARM command signals detected with the falling
(Note) edge.
POSI During exposure, H level signals are output.
NEGA
During exposure, L level signals are output.
(Note)
POSI During the ARM mode, H level signals are output.
NEGA
During the ARM mode, L level signals are output.
(Note)
POSI During a FAULT status, H level signals are output.
NEGA
During a FAULT status, L level signals are output.
(Note)
7-13
