Adjust the Image Quality of the
Video
You can adjust the image quality when using the VIEW mode before recording. (A 4-37 )
Image quality adjustment can be performed on the following items.(the same details as the
live image quality adjustment during the VIEW mode)
Digital Gain Adjusts the sensitivity. Changes the brightness of the entire image.
White Balance Corrects the color to properly reflect white based on various light sources.
Enhance Adjusts the contour enhancement.
Chroma Adjusts the gradation properties (darkness, brightness shown).
Gamma Adjusts the chroma .
Knee Lowers the gain for the bright areas and expands the dynamic range.
RGB Matrix Improves the color reproduction.
Luminance Sets the input/output properties for brightness.
•The image quality settings for playback videos are also reflected in videos that are
saved and downloaded.
•If dividing the memory into segments and recording, the image quality settings
can be made separately for each segment.
•Settings for live videos in the VIEW mode and the ARM mode cannot be changed
even if the image quality settings for the playback video are changed.
Set the Luminance Properties (Luminance - LINEAR)
1 Select the play settings tab icon
2 Select inside the Image...tab box
Select the box under Luminance
3
•A popup window is displayed
Select an item from the popup win-
dow
•Select LINEAR
4
Ignore the settings for gain, gamma
and knee, and the data is converted
to linear and displayed.
(00471)H

Adjust the Image Quality of the Video

4
5-9
