14 Input output signal

14.1 Digital Input

The REVO CL thyristor unit has 2 digital inputs opto-isolated to 24Vdc 5 mA.
You can activate the inputs with the internal supply or with an external source for example the PLC.

14.1.1 Start/Stop (Terminal 3 of M1)

This is the start command (Enable) of the REVO CL.
If you Remove the Start command the REVO CL thyristor unit will be stopped and the output will return
at zero.

14.1.2 Configurable Input (Terminal 4 of M1)

This digital input is configured by the parameter  and could perform different functions:
Enable:
•
This function forces the output at zero.
Feed-Back Selection:
•
With this function, when you active the input, the feed-back setted in the parameter  change in
Voltage Feed-Back (V).
Analog/Digital Setpoint(Local/Remote):
•
With this function, when you active the input, the setpoint reference change from Analog input to
Digital value in bumpless mode, setted in the parameter  . The parameter SP is not stored in
memory.
Change Firing type:
•
With this function, when you active the input, the Firing type setted in the parameter  change in
Phase Angle PA.
14.2 Digital Output
The REVO CL thyristor unit has 1 relay output on terminal 9-10 of terminal block M1(Max 500mA,
125Vac). The functionality of this output cane be setted with the parameter 
This digital output can be configured in order to activate itself after that one of these alarms occours:
HB and SC alarm are active.
•
Only HB alarm is active.
•
Only SC alarm is active.
•
CD-Eng-REVO-CL-1PH-60-210A-Thyristors-Units
(terminal 9-10 of M1)
