7 Basic Connections and sizing
Single phase wiring with resistive load (with REVO CL-1PH)
P
I =
V
V = Nominal voltage of the load
I = Nominal current of the load
P = Nominal power of the load
Single phase wiring with inductive load (with REVO CL-1PH)
P
I =
φ
V
cos
V = Nominal voltage phase to phase
I = Nominal current to the load
P = Nominal power to the load
Open Delta wiring with resistive load (with 3 X REVO CL-1PH)
P
=
I
3
V
V = Nominal voltage of the load
I = Nominal current of the load
P = Nominal power of the load
