Digital input 1 configuration :
Parameter Parameter
Display Name
Digital input 1

CDi1
configuration
Sample Values and Note
0 = Enable
1 = Change To V FeedBack
2 = L/R Enable
3 = Change Firing PA/xx
Digital input 2 configuration :
Parameter Parameter
Display Name
Digital input 2

CDi2
configuration
Sample Values and Note
0 = Enable
1 = Change To V FeedBack
2 = L/R Enable
3 = Change Firing PA/xx
Digital Output 1 configuration :
Parameter Parameter
Display Name
DigitalOut. 1

CDo1
configuration
Sample Values and Note
0 = Enable HB SCR
1 = Enable SCR Current Limit
2 = Enable HB Current Limit
3 = Enable Current Limit Alarm
4= Enable HB SCR
 
 
5 = Enable SC Alarm
    
 
6 =Enable HB Alarm
7=Disable HB SCR I Limit
