12.5 Power Terminals
Warning: Before connecting or disconnecting the unit check that power and control cables
are isolated from voltage sources.
Terminal
L1 Line Input Phase 1
T1 Load Output Phase 1
12.6 Command Terminals
Warning: Before connecting or disconnecting the unit check that power and control cables
are isolated from voltage sources.
12.6.1 Terminal block M1
Terminal
1 GND
2 COM I - Common Digital Input
3 DI 2 – Enable Digital Input
4 DI 1 - Configurable Input
5 + Control Input (SSR/0-10Vdc/4-20mA)
6 - Control Input (SSR/0-10Vdc/4-20mA)
7 Output +10Vdc stabilized 1 mA MAX
8 + Ext CL - External Current Profiler
9 C - Common contact alarm relay output (see HB Alarm contact for config.)
10 NC\NO -Normally Close\Open contact alarm relay output (see HB Alarm contact for config.)
11 RS485 A
12 RS485 B
12.6.2 Terminal block M2
Terminal
Aux – Voltage Supply for elettronic boards and syncronizzation (
L1
- Not Connected
Aux – Voltage Supply for elettronic boards and syncronizzation (
L2/N
12.6.3 Terminal block M3 (only from 120 to 210A)
Terminal
F1 Fan supply (230V Standard – 115V Option)
F2 Fan supply (230V Standard – 115V Option)
CD-Eng-REVO-CL-1PH-60-210A-Thyristors-Units
REVO CL
Description
Description
Description
Description
18
User's Manual
See order code for the Value)
See order code for the Value)
