Quick start

The STM32 Nucleo-64 board is a low-cost and easy-to-use development kit, to evaluate and start development
quickly with the STM32 Nucleo-64.
Before installing and using the product, accept the evaluation product license agreement from the
epla webpage. For more information on the STM32 Nucleo-64 board and the software example, visit the
www.st.com/stm32nucleo
5.1

Getting started

Follow the sequence below to configure the STM32 Nucleo-64 board and launch the demonstration application
(refer to Figure 3
1. Check jumper positions on board (refer to
2. To identify correctly all device interfaces from the host PC, install the STLINK-V2EC USB driver available on
the www.st.com/stm32nucleo
3. To power the board, connect the STM32 Nucleo-64 board to a PC with a USB Type-A or USB Type-C
USB Type-C
the COM LED (LD4) lights up red.
4. Press the blue user button (B1).
5. Observe that the blinking frequency of the LEDs (LD1, LD2) changes, by clicking on the user button (B1).
6. Download the demonstration software and several software examples that help to use the STM32 Nucleo-64
features. These are available on the
7. Develop your application using the available examples.
Jumper
JP5
JP1
JP3
JP2, JP4, and JP6 to
JP8
UM3353 - Rev 1
webpage.
for component location):
webpage, before connecting to the board.
®
through the USB connector (CN1). Once powered on, the PWR green LED (LD3) lights up and
www.st.com
Table 4.
Definition
IDD measurement
5 V power selection
STLK reset
SWD interface
Table 4. Default jumper configuration).
website.
Default jumper configuration
Default position
ON STM32 VDD current measurement
[1-2] 5 V power supply from ST-LINK USB
OFF No STLK reset
ON On-board STLINK-V2EC debugger
UM3353
Quick start
www.st.com/
®
to
Comment
