7.2

ST morpho connectors (CN7 and CN10)

The ST morpho connectors are two 2.54 mm pitch male pin headers (CN7 and CN10). They can be used to
connect the STM32 Nucleo-64 board to an expansion or a prototype/wrapping board placed on top of it. All
signals and power pins of the STM32 are available on the two ST morpho connectors. A logic analyzer or a
voltmeter can also probe this connector.
Table 12 describes the CN7 and CN10 connector pinout.
Table 12.
Pin name Pin number Pin number
PC10 1
PC12 3
VDD 5
PD4 7
PD0 9
PD3 11
(1) 13
PA13
PA14 (1) 15
PC6 17
GND 19
PC2 21
PC13 23
(2)
PC14 25
(2) 27
PC15
PF0 (2) 29
(2) 31
PF1
PF3 33
PB2 35
PB11 37
1. PA13 and PA14 are shared with SWD signals connected to STLINK-V2EC, it is not recommended to use them as I/O pins.
2. Refer to Section 6.5 for details.
3. Refer to Section 6.10 for details.
4. The ADC input range is 0 <= VIN <= VREF.
UM3353 - Rev 1
Pin assignments for the STM32 on the ST morpho connectors
CN7
Pin name
2 PC11
4 PD2
6 5V_EXT
8 GND
10 PD1
12 3V3
14 NRST
16 3V3
18 5V
20 GND
22 GND
24 VIN
26 PD5
28 PA0
30 PA1
32 PA4
34 PB0
36 PC4
38 PC5
CN10
Pin name Pin number Pin number
PC3 1
PB8 3
PB9 5
VREF (4) 7
GND 9
PA5 11
PA6 13
PA7 15
PA15 17
PB3 19
PA9 21
PA8 23
PC8 25
PB4 27
PB5 29
PC7 31
PA10 33
PB6 35
PB7 37
UM3353
Connectors
Pin name
2 PC9
4 PC1
6 PA3
8 5V_STLK
10 PD6
(3)
12 PA12
14 (3)
PA11
16 PB12
18 PA2
20 GND
22 PC0
24 PB1
26 PB15
28 PB14
30 PB13
32 GND
34 PB10
36 PD8
38 PD9
