Quick start

Before installing and using the product, accept the evaluation product license agreement from the
epla webpage.
Follow the sequence below to configure the STM32U5G9J-DK2 Discovery board and launch the demonstration
application (refer to
1. For the correct identification of all the device interfaces from the host PC and before connecting the board,
install the STLINK-V3EC USB driver available on the
2. Check that the JP1 jumper (5V power source selection) is set on [1-2] selecting 5V from STLINK-V3EC
(STLK) and JP4 (VDD_MCU current measurement) is ON powering the microcontroller. Refer to
3. Connect the STM32U5G9J-DK2 Discovery board to a PC with a USB cable (USB Type-A or USB Type-C
USB Type-C
4. Then, the 5V_PWR green LED (LD1) lights up and the COM LED (LD7) blinks.
5. The LCD module displays a menu with icons, indicating the demonstration application software startup.
6. The demonstration application software and its user manual, as well as other software examples for exploring
STM32U5G9J-DK features are available on the
7. Develop your application using the available examples.
Jumper
JP1 5 V power source selection
JP4 IDD measurement
1. The default setting is in bold.
UM3223 - Rev 1
Figure 5 for component location):
®
) through the STLINK-V3EC USB connector (CN8) to power the board.
Table 4.
Function
www.st.com website.
STM32CubeU5 webpage.
Default jumper setting
(1)
Setting
[1-2] 5 V from STLINK-V3EC (STLK)
ON VDD_MCU current measurement
UM3223
Quick start
www.st.com/
Table 4.
®
to
Comment
