10. Replacing the Release Film
a.
Remove the 14 screws at the bottom of the filament
tray to remove the worn-out release film.
b.
Take. Remove the protective film on both sides of the
release film and take a new release film, and then place
the new release film between the two steel rings.
c.
Put the installed steel rings back into the filament tray
and tighten the 14 screws.
d.
The installed release film is as shown in the images
below.
Parameters
Specifications
Dimensions: 140 mm x 200 mm
Thickness: 0.15 to 0.2 mm
Light Transmittance: 95%
（Light Transmittance）
08
