4

WIRING

3
WIRING
3.1
Pinouts
A
Analogue input
B
Function pins
C
Power supply
D
Relay output
E
Serial output
F
Analogue output
3.2
Position the input header
THE INPUT HEADER IS FACTORY POSITIONED FOR 0/4-
20MA INPUT. MA INPUT USERS SKIP THIS STEP.
NB: Follow these instructions ONLY if you are
switching the input from current
Remove the backing plate by inserting a
screwdriver into the indents (indicated on the
diagram). Then gently slide the input module
from the case (see 3.1A to identify the input
module).
TEX-BAR-MAN-11V04 (SEP11)
(see 3.3)
(see 3.7)
(see 3.8)
(see 3.4)
(see 3.6)
(see 3.5)
voltage.
A
B
C
D
E
F
Copyright © 2011
