Define Instruments PRO-WEI100 Manual

Order Codes
PRO-WEI100 Strain gauge input
-HV 85-265V AC / 95-370V DC
-LV 15-48V AC / 10-72V DC
Options
-R2
2 x relay outputs
-R4 4 x relay outputs
-A 1 x mA/V analog output
-S2R 1 x RS232 (RJ11 terminal)
-S4S 1 x RS485 (screw terminal)
Copyright © 2019 Define Instruments
PRO-WEI100
Weighing Controller
This intelligent weighing controller ac-
cepts input directly from a 4-wire or a
6-wire strain gauge.
The PRO-WEI100 has a number of ad-
vanced functions designed specifically
for the weighing industry, and is simple
to set up and operate. It also features
output and input isolation, eliminating
the need for any special consideration
when interfacing to analog/serial in-
puts, or PCs/PLCs/HMIs.
Contents
1 Specifications ............................. 2
2 Features ....................................... 3
3 Front Panel & Display ................. 6
4 Wiring ........................................ 8
5 Dimensions & Installation ........ 11
6 Input Setup & Calibration ....... 13
7 Setpoint Setup ........................... 24
8 Setpoint Direct Access .............. 27
9 Reset PIN Numbers .................. 27
10 Factory Analog Output
Calibration ................................. 28
A Appendix A - Input Functions ... 29
B Appendix B - Serial Modes ........ 31
PRO-WEI100-MAN-19V01 (0225)
1
