2

GENERAL INFORMATION

Input signal
Power supply
Relay output
Excitation
Sampling rate
Resolution
Accuracy
Temperature drift
Calibration
Security
OPTIONAL FEATURES
Analogue output Isolated 16-bit analogue output (fully scaleable). Can be wired
Serial port
Copyright © 2011
Current (0-20mA, 4-20mA) or Voltage (0-2V, 0-10V)
HV (85-265V AC/95-370V DC) or LV (15-48V AC/10-72V DC)
Choose between 2 or 4 x 5A Form A relays
24V DC (50mA
MAX
10Hz
16 bit
0.05% of reading
50ppm/°C
TYPICAL
Factory calibrated for 4-20mA. Automatic or manual user
recalibration available.
Setup and setpoint functions have independent security code
access. Setpoint functions are independently configurable, and
accessible through the
for current (4-20mA) or voltage (0-10V). Window program-
mable over any range within the controller's full-scale range.
Isolated RS232 or RS485
Modes: ASCII, Modbus RTU slave, Ranger A output
Data rates: 300-38400 baud. Parity: Odd, even or none.
GENERAL INFORMATION
)
key.
F2
TEX-BAR-MAN-11V04 (SEP11)
3
