COMPONENT CHECKLIST

AWM 130 Arm
AWM-A13T
Product Quantity
1
AWM 710 Arm
AWM-A71T
Product Quantity
2
400 Post
AWM-P40G
Product Quantity
1
DESK FIXING OPTIONS
Below are the fixing options available for this solution. Fixing installation guides are supplied with the product
or can be accessed through Atdec's website, along with detailed product specifications.
NOTE: Chosen desk fixing must be added to this solution code when ordering.
BOLT
THROUGH
AWM-FB
F CLAMP
AWM-FF
A
Monitor Arm
(x1)
A
Monitor Arm
(x1)
A
Post
(x1)
B
Post
Cap
(x1)
C CLAMP
AWM-FC
B C
Screw Security
M4x10mm Screw
(x4) (x1)
B
VESA Head
(x1)
D E
Screw Security
M4x10mm Screw
(x4) (x1)
C D
Screw Cable Cover
M8 Cap
(x2) (x4)
HEAVY DUTY
F CLAMP
AWM-FH
AWMS-3-13714 Page 2 of 6
D
4mm
Hex Key
(x1)
C
Channel Clamp
(x1)
F
4mm
Hex Key
(x1)
E
Cable
Cover
(x2)
GROMMET
CLAMP
AC-GC
