AWM 130 Arm
COMPONENT CHECKLIST
A
Monitor Arm
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! Do not remove or throw away the plastic sleeve on the channel clamp.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec AWM Series Posts and Wall Channels
! This product is not suitable for outdoor use or mobile applications
! Do not over-tighten screws and adjustment points on product.
! VESA mounted accessories (such as mini PC brackets and mounts), and offset VESA locations, and unevenly weighted monitors
(relative to the center of the VESA mounting interface) exert additional leverage that can exceed the capacity of the mount even
though the monitor weight may be within the stated range. Please contact Atdec if you would like further information.
B
C
Screw
Security
M4x10mm
Screw
(x4)
(x1)
Installation Guide
REQUIRED TOOLS
• Phillips Head Screwdriver
WEIGHT RANGE
Flat Monitor
D
0 - 12kg
4mm
(0 - 26.5lb)
Allen Key
Curved Monitor
(x1)
0 - 10kg
(0 - 22lb)
Curved monitors with an overall
depth up to 140mm (5.5").
Monitor weight should be within the
weight range of all modular elements
that make up the complete monitor
mounting solution.
AWM-A13T
AWM-A13T Page 1 of 3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Atdec AWM 130 Arm
Summary of Contents for Atdec AWM 130 Arm
- Page 1 (relative to the center of the VESA mounting interface) exert additional leverage that can exceed the capacity of the mount even though the monitor weight may be within the stated range. Please contact Atdec if you would like further information.
- Page 2 1. Fix arm to post or wall channel 1.1 Ensure knob is undone. 1.2 Slide channel clamp into channel. 1.3 Hold arm at desired height on channel and turn knob to lock in place. Push knob to aid insertion 2. Attach VESA head to monitor 2.1 Slide release switch up and 2.2 Check Note: Recessed 75x75...
- Page 3 No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer AWM-A13T Page 3 of 3 reserves the right to alter specifications without notice. ©20231212...
