Evaluation Board User Guide
22 2 R3, R12
23 0 R4, R18
24 2 R6, R13
25 1 R7
26 1 R10
27 3 R11, R16, R20
28 1 R19
29 0 R21, R22
30 1 R14
31 1 U2
32 1 U3
33 1 U4
HARDWARE: FOR EVALUATION BOARD ONLY
1 5 E1, E2, E3, E4, E5
E6, E7, E8, E9, E10,
2 8 E11, E12, E13
3 4 J1, J2, J3, J4
4 1 J5
5 2 J6, J7
6 1 JP1
MP1, MP2, MP3,
7 4 MP4
8 1 SW1
9 1 XJP1
analog.com
RES., 866Ω, 1%, 1/10W, 0603
RES., OPTION, 0603
RES., 4.99kΩ, 1%, 1/10W, 0603
RES., 10mΩ, 1%, 3W, 6.3 X3.1mm
RES., 49.9Ω, 1%, 1/10W, 0603
RES., 0Ω, 1/10W, 0603
RES., 36.5kΩ, 1%, 1/10W, 0603
RES., OPTION, 0603
RES., 1MΩ, 1%, 1/10W, 0603,
IC, EEPROM, 2Kb (256x8), TSSOP-8
IC, 2.6A, 2.5V-5.5V IDEAL DIO, 10DFN
IC, 200mA LDO, MSOP-8
TEST POINT, TURRET, 0.064"
TEST POINT, TURRET, 0.094"
BANANA JACK, FEMALE
CONN., HDR, MALE, 2x6,2mm
CONN., BNC, 50Ω
CONN., HDR, MALE, 1x3, 2mm
STANDOFF, NYLON, SNAP-ON, 0.50"
SWITCH, SLIDE, DPDT, 0.3A, 6VDC, PTH
CONN., SHUNT, FEMALE, 2-POS, 2mm
EVAL-LT7170-1-AZ
VISHAY, CRCW0603866RFKEA
PANASONIC, ERJ3EKF4991V
SUSUMU, KRL6432E-C-R010-F-T1
PANASONIC, ERJ3EKF49R9V
VISHAY, CRCW06030000Z0EA
YAGEO RC0603FR‐0736K5L
NIC, NRC06F1004TRF
MICROCHIP, 24LC025-I/ST
ANALOG DEVICES,
LTC4413EDD#PBF
ANALOG DEVICES, LT3063EMS8E-
3.3#PBF
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
AMPHENOL, 98414-G06-12ULF
AMPHENOL RF, 112404
WURTH ELEKTRONIK, 62000311121
KEYSTONE, 8833
C&K, JS202011CQN
WURTH ELEKTRONIK, 60800213421
Rev. A 9 of 13
