Powering Off

From any screen, power
can be turned off by
Powering
selecting Pwr Off in the
O . . .
power menu, holding
the Power Button
and waiting for the
moving bar to progress,
or with the programmable switch (if
it is configured for this function).
If the power button is released,
or the top panel switch is turned
back on again before the moving
bar progresses, the unit will remain
turned on and the LCD will return to
the same screen or menu that was
displayed previously.
NOTE: If the
programmable switch
is in the OFF position,
power can still be turned
on with the power button.
If the programmable
switch is then turned
on, a brief message will
appear on the LCD.
Recorder Operating
Instructions
• Install battery(s)
• Insert microSDHC memory
card
• Turn power on
• Format memory card
• Connect microphone and
place it in the position where
it will be used.
• Have the user talk or sing at
the same level that will be
used in the production, and
adjust the input gain so that
the -20 LED blinks red on
louder peaks.
Rio Rancho, NM
Digital Hybrid Wireless Belt-Pack Transmitters
Input...
Gain
Rolloff
Polarity
Use the UP and DOWN arrow buttons to
adjust the gain until the -20 LED blinks
in
• Press MENU/SEL, choose SD-
Card and Record from the menu
SDCard...
Record
Files
Takes
• To stop recording, press MENU/
SEL, choose SDCard and Stop;
the word SAVED appears on the
screen
SDCard...
Stop
Files
Takes
NOTE: Record and Stop
Recording may also be
achieved by shortcut
keys from the main/home
screen:
• Simultaneous press of
BACK button + UP arrow
button: Begin record
• Simultaneous press of
BACK button + DOWN
arrow button: Stop
record
Gain
22
-40 -20 +0
red on louder peaks
RECORD-
ING
SAVED
542.000
REC
-40 -20 +0
542.000
-40 -20 +0
