Lectrosonics DBSM Quick Start Manual page 12

DBSM-A1B1, DBSM/E01-A1B1, DBSMD-A1B1, DBSMD/E01-A1B1
Setting Frame Rate
TCode... Fr. Rate
TC Jam
Fr. Rate
Use Clk
The frame rate affects embedding of
the timing reference in the .BWF file
metadata and display of timecode.
The following options are available:
• 30 • 23.976l
• 29.97 • 30DF
• 25 • 29.97DF
NOTE: While it is
possible to change the
frame rate, the most
common use will be to
check the frame rate
which was received
during the most recent
timecode jam. In rare
situations, it might be
useful to alter the frame
rate here, but be aware
that audio tracks many
not line up correctly with
mismatched frame rates.
Use Clock
The DBSM time clock and calendar
(RTCC) cannot be relied on as an ac-
curate time code source. Use Clock
should only be used when there is
no need for the time to agree with an
external timecode source.
TCode...
LOADING
TC Jam
TIMECODE
Fr. Rate FROM
Use Clk CLOCK
12
30
• 24
IR&Key Menu
SendFreq
Press MENU/SEL to sync the
Frequency to another transmitter or
receiver via the IR port.
IR&Key...
SendFreq
SendFreq
SendAll
GetFrq
Sync-->
SendAll
Press MENU/SEL to sync: Fre-
quency, Transmitter Name, Talkback
Enabled, and Compatibility Mode to
another transmitter or receiver via
the IR port.
NOTE: SendAll does
not send Encryption
Key. This must be done
separately.
IR&Key...
SendFreq
SendAll
GetFrq
GetFreq
Press MENU/SELto sync Frequency
to another transmitter or receiver via
the IR port.
IR&Key...
GetFrq
SendFreq
SendAll
GetFrq
Sync-->
GetAll
Press MENU/SEL to sync: Frequen-
cy, Transmitter Name, Talkback
Enabled, and Compatibility Mode
from another transmitter or receiver
via the IR port.
LECTROSONICS, INC.
SendAll
Sync-->
