Q
uick
S
tart
G
uide
DSSM
Digital Wireless Water-Resistant
Micro Body Pack Transmitter
DSSM-A1B1, DSSM-B1C1, DSSM/E01-A1B1,
DSSM/E01-B1C1, DSSM/E07-941
Fill in for your records:
Serial Number:
Purchase Date:
This guide is intended to assist
with initial setup and operation of
your Lectrosonics product.
For a detailed user manual, down-
load the most current
version at:
www.lectrosonics.com
25 March 2024
Advertisement
Related Manuals for Lectrosonics DSSM-A1B1
Summary of Contents for Lectrosonics DSSM-A1B1
- Page 1 DSSM Digital Wireless Water-Resistant Micro Body Pack Transmitter DSSM-A1B1, DSSM-B1C1, DSSM/E01-A1B1, DSSM/E01-B1C1, DSSM/E07-941 Fill in for your records: This guide is intended to assist with initial setup and operation of Serial Number: your Lectrosonics product. For a detailed user manual, down-...
- Page 2 - like dirt, dust and sand. The DSSM’s IP57 rating indicates that that it is water resistant up to 1 meter (3.2 feet) for 30 minutes - perfect for your most demanding environments. LECTROSONICS, INC.
- Page 3 The DSSM offers an extensive feature set and performance packed into an exception- ally compact housing, compatible with all current Lectrosonics digital receivers, including the DSR, DSR4, DSQD, DCR822, M2Ra and DCHR. The DSSM includes specially developed,...
-
Page 4: Controls And Functions
BATT LED and Battery Indicator The battery LED glows green when the battery is good, and the battery icon is solid and steady. The LED color changes to red when there is limited operating LECTROSONICS, INC. -
Page 5: Menu/Sel Button
• StandBy: Blue LED is OFF and Operating Mode Indicator icon has a line through it 564.800 when • Missing/Wrong Key: LED is FLASHING unit is transmitting, along with <-KEY?-> flashing below the Operating Mode Indicator. <-KEY?-> •Transmitting: Blue Light is steadily ON when key is valid. www.lectrosonics.com... - Page 6 The battery door has a Gore-Tex® sealed vent to allow air pressure to escape while blocking moisture ingress. The USB port, which is used for firmware updates, is located inside the battery compartment. When connected, the unit is powered from the USB source. LECTROSONICS, INC.
-
Page 7: Battery Installation
Insert battery into compartment, CAUTION: Use only the contact end first. Line the contacts Lectrosonics LB50 battery and on the battery up with the contacts Lectrosonics battery chargers. on the unit, then press the back end of the battery into compartment. - Page 8 A u t o O n ? BACK and return Y e s LECTROSONICS, INC. Toggle option with arrow buttons R e m o t e to select E n a b l e R e m o t e...
- Page 9 D e f a u l t and return Y e s D S S M A b o u t V 2 . 0 8 / 2 . 0 1 to go back BACK B l k : 9 4 1 www.lectrosonics.com...
- Page 10 Encryption Key is missing. Refer to page 14 in the Operator’s Manual for instructions on setting the Encryption Key. The DSSM ships with the key type set as 564.800 “Universal” and will work right away with any receiver also set to Universal Key Type. <-KEY?-> LECTROSONICS, INC.
- Page 11 The following list outlines the steps necessary to set up the transmitter for normal use. 1) Install a charged Lectrosonics LB-50 battery or retrieve the charged unit from the charging dock. 2) Set the compatibility mode to match the receiver to be used by pressing MENU/SEL, then scrolling to COMPAT and pressing MENU/SEL again to choose either D2 or HDM.
-
Page 12: Locking The Controls
4) Use the arrow buttons to adjust the gain until the –10 dB glows LECTROSONICS, INC. - Page 13 616-617 MHz: 1 MHz buffer (unavailable for use) phones used in this part of the The Duplex Gap consists of: spectrum. 652-653 MHz: 1 MHz buffer (unavailable for use) 653-657 MHz: 4 MHz (licensed operators only) 657-663 MHz: 6 MHz (unlicensed and WSDs) www.lectrosonics.com...
- Page 14 DSSM transmitters in larger systems with numerous batteries in regular use. Each charging module may be daisy-chained to 3 additional modules using a single AC-DC power supply (DCR5/9AU - not included) for a total of 16 units charging at once. LECTROSONICS, INC.
- Page 15 www.lectrosonics.com...
-
Page 16: Limited One-Year Warranty
This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
