SSV Works X32-PHZ2A Manual page 4

REAR CAGE POD PARTS LIST
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or
workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects in
material or workmanship. All SSV Works Speakers are covered by a limited 1 year warranty against
defects in material or workmanship. Labor for replacement of defective components is not covered.
Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- 5mm Allen Key
PARTS LIST IMAGES
US-C65 Enclosures (1 pair)
M6 Hex Head Bolts &
Washers x4
INSTALLATION NOTES
It is recommended to wrap the bag that the clamps come in around the cage before you slide the clamp onto the cage to prevent scratching.
4
- 8mm Open End Wrench
Dual Mounting Ring Adapter
x 2
M6 Set Screws x 4 Rear Speaker "Y" Harness
!
Placement of the pod depends on what type of roll
cage you have (factory or aftermarket) and your
preference of where you want the pods to be installed.
In these instructions, we have installed them on the
outside vertical bars at the back of the roll cage.
INCLUDES 1.85" CLAMP -
AFTERMARKET ROLL CAGE
MAY REQUIRE A DIFFERENT
CLAMP SIZE
Ring Clamp x 4
Audio Extension Harness
8 ft. (B-H1913)
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
M6 Allen Socket Head Bolts &
Washers x4
Audio Extension Harness
2 ft. (B-H1912)
