SSV Works X32-PHZ2A Manual page 12

REAR CAGE POD INSTALLATION
A. Find the best orientation for the speaker on your bar and
screw in the Set Screws in the OPPOSITE holes of where the
clamp will install into.
C. Place both ring mounting clamps on the cage using the plastic bag to prevent scratching, place the cage mount pod in its final mounting location and
secure to the clamps using the two (2) M6 allen socket head bolts and washers with a 5mm allen key.
PLACEMENT OF THE POD DEPENDS ON WHAT TYPE OF ROLL CAGE YOU HAVE (FACTORY OR
AFTERMARKET) AND YOUR PREFERENCE OF WHERE YOU WANT THE PODS TO BE INSTALLED. IN
THESE INSTRUCTIONS, WE HAVE INSTALLED THEM ON THE OUTSIDE VERTICAL BARS AT THE BACK
12
A
C
OF THE ROLL CAGE.
B. Loosely install the clamp base to the cage mount pod with the
two (2) M6 hex head bolts and washers, place the cage mount
pod in the desired mounting location on the vehicle. Once the
ring adapter is in the desired position, tighten the two (2) bolts
using a 8mm open wrench.
C
B
