SSV Works X32-PHZ2A Manual page 10

F. Place (4) M6 T30 screws and washers into each drilled hole. Fasten
from the bottom a washer and M6 nut. Secure each screw with
10mm wrench and T30 torx driver.
H. Route the MR1 power harness and 500.1 audio input and any other
related accessories out of the cutout.
J. Place the MR1 into the DMR1. When placing the MR1 into the dash
mount, feed slack wiring back into the dash cavity cut out. This will
allow for proper fitment of the MR1.
10
F
G. Using a #2 phillips screwdriver, secure the front of the base plate
with the provided (2) #6 x ½" screws.
H
I. Place the DMR1 over the base plate with the harness routed out of it.
J
K. Secure the MR1 with the (4) M3.5 screws provided with the MR1.
The top (2) screws will thread into the DMR1. The lower (2) screws
will go through the DMR1 and into the threads of the base plate.
G
I
K
