Table Of Contents - Baby Lock Mid-Line Machines Technical Training Manual

4
Adjustment
Inspection Needle point damage .............................................. 4 - 2
Test Mode Start test mode ........................................................ 4 - 3
Adjustment Touch panel............................................................. 4 - 4
Timing belt tension .................................................. 4 - 5
Timing belt and belt support upper/lower clearance ..... 4 - 6
Motor belt tension.................................................... 4 - 7
Fine tension............................................................. 4 - 8
Upper thread tension............................................... 4 - 9
Front/back position of needle and presser foot ..... 4 - 10
Left base line needle drop ..................................... 4 - 11
Needle clearance left/right..................................... 4 - 12
Needle bar rising ................................................... 4 - 13
Needle bar height .................................................. 4 - 14
Needle clearance .................................................. 4 - 15
Needle threader..................................................... 4 - 16
Needle bar release ................................................ 4 - 17
Presser bar height ................................................. 4 - 19
Fabric thickness setting......................................... 4 - 20
Feed dog height and parallelism ........................... 4 - 21
Front/back and left/right position of feed dog ........ 4 - 23
Feed forward/backward......................................... 4 - 24
Side feed straight stitch ......................................... 4 - 26
One point............................................................... 4 - 27
BH lever switch position ........................................ 4 - 28
Inner rotary hook bracket position ......................... 4 - 30
Lower thread tension (standard inner rotary hook assy) ... 4 - 31
Belt tension (embroidery unit) ............................... 4 - 32
X carriage height (embroidery unit) ....................... 4 - 33
Embroidery center position (embroidery unit) ....... 4 - 34
F pulse motor phase.............................................. 4 - 36
4 - 1
