- Page 1 Getting to Know: A-Line SerieS Model BL67 Baby Lock Consumer Helpline: 800-313-4110 www.babylock.com...
- Page 2 Lock Retailer about Audrey’s friends in the A-Line, like Lauren, Natalie, Maria and Grace. From classic tailored looks to modern-day fashions, the machines in the A-Line Series will help you sew and serge with success – all with the quality you’ve come to expect from Baby Lock.
-
Page 3: Winding The Bobbin
Winding the Bobbin reMOVinG THe BOBBin Remove the bobbin cover by sliding the release lever to the right and push down the left corner of bobbin cover at the same time. 2. Remove the bobbin from the machine. WINDING THE BOBBIN WinDinG THe BOBBin 1. -
Page 4: Inserting The Bobbin
inserting the Bobbin 1. Place the bobbin into the bobbin holder with the thread unwinding counterclockwise. 2. Draw the thread into notch (A). 3. Pull the thread toward the left and along the inside of spring (B) until it slips into notch (C) being sure that thread does not slip out of notch (A). -
Page 5: Threading The Machine
Threading the Machine THreADinG THe UPPer THreAD 1. Raise the presser foot lever. 2. Press the needle up / down button or rotate the handwheel toward you to raise the needle in the up position. 3. Place a spool of thread onto the spool pin and secure with the proper size spool cap. 4. -
Page 6: Using The Needle Threader
Using the needle Threader 1. Lower the presser foot. 2. Set needle in up position. 3. Lower the threader slowly and draw thread through thread guide (A) and pull toward the right. 4. Lower the lever as far as it will go. The threader will turn and the hook pin will go through the needle eye. 5. -
Page 7: Drawing Up The Bobbin Thread
raising the Lower Thread DrAWinG UP THe BOBBin THreAD 1. Raise the presser foot. 2. Hold the upper thread loosely and press needle up/down button, which is the first button on the right. The handwheel will turn one complete turn once you push this button. 3. -
Page 8: Selecting The Stitch
Selecting the Stitch SeTTinG THe STiTCH WiDTH AnD STiTCH LenGTH Preset stitch length and stitch width are indicated by the number of LED lights. The longer or wider the stitch length/stitch width is, more of the LED lights are on. Some stitches have a blinking light which indicates the setting between two LED lights. -
Page 9: Starting To Sew
Starting to Sew The machine will be set at 01 automatically to sew straight stitches when the power switch is turned on. 1. Raise the presser foot. 2. Place the fabric under the presser foot. 3. Lower the presser foot. 4. -
Page 10: Seaming Guide On The Stitch Plate
Starting to Sew reVerSe STiTCHinG Reverse stitching is used for reinforcing the ends of the seams. 1. Place the fabric in position where back stitching is to be made and lower the presser foot. 2. Press reverse stitch button and sew 4-5 stitches. (If using the foot control, press pedal while pressing reverse stitch button.) 3. - Page 11 7. Encase the top edge of the pocket strip (37” Supplies: length) with the bias tape. Using a straight stitch, • Baby Lock Audrey Sewing Machine sew 1/8” from the edge of the bias tape securing • 3/4 yard cotton print fabric for background it to the top edge of the pocket strip.
- Page 12 Audrey's Wall Organizer Continued 10. Lay the pocket piece over the 23” background square for measurement reference. On the pocket piece, at each division, you will make a pleat on each side that has a 1” depth. 11. To make the pleats, measure 1” from the end of the two pocket pieces; fold a pleat that measures 1” deep.
