Under Desk Large Keyboard Tray with
Swinging Height Adjustment
Instruction Manual
SKU: MOUNT-KB34S
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-kb08s
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-KB34S
Summary of Contents for Vivo MOUNT-KB34S
- Page 1 Under Desk Large Keyboard Tray with Swinging Height Adjustment Instruction Manual SKU: MOUNT-KB34S Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-kb08s GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Assembly Steps
If you do not understand these directions, or if you have any doubts about the safety of the installation, STEP 1 please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause Assemble Keyboard Tray Set (A) by placing Connecting Plates (B) into the insets on underneathside of damage or serious injury. - Page 3 STEP 4 STEP 3 Unfold the Adjustable Brackets (C) by pressing down on the levers and pulling the Secure Height Adjustable Bracket Set (C) to the sides of Keyboard Tray (A) using M5x12mm top bracket up. Make sure the brackets are adjusted to the same level for installation. Screws (S-A) and a Phillips screwdriver.
- Page 4 STEP 5 ASSEMBLY COMPLETE Hold Mounting Template (T-A) to the underside of desk, 0.5” (12mm) from the edge and mark hole Keyboard tray is now ready for use. locations. Underside of Desk Desktop 0.5”/12mm from desk edge Drill 3/8” (10mm) deep holes using a 1/8” (3mm) drill bit. Mount keyboard tray assembly using M5x14mm Screws (S-B) and a Phillips screwdriver.
- Page 5 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
