- Page 1 Bamboo Clamp-on Keyboard Tray SKU: MOUNT-KB05O Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-kb05e...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 Package Contents B (x2) A (x1) Slider Bracket Keyboard Tray D (x2) C (x2) Clamp Included Hardware & Tools S-A (x8) S-A (x6) M5x12mm Round M4x7mm Flat Head Screw Head Screw Tools Needed: Weight Capacity: 11lbs (5kg) Phillips Screwdriver...
-
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Assemble Slider Brackets (B) to Clamps (C) using M4x7mm Screws (S-A), and a Phillips screwdriver. Need the Tray to Pull Out Further? The Clamp can be offset using the extra holes in Slider Brackets (B) to allow the tray to be pulled out an extra 1.2”... - Page 5 STEP 2 Connect slider assembly to Keyboard Tray (A) using M5x12mm Round Head Screws (S-B), and a Phillips screwdriver. The clamps must be on the opposite end from the center cable guide.
- Page 6 STEP 3 Place Pads (D) on the underside of each clamp. Place assembled keyboard mount on edge of desk and tighten clamps. NOTE: To ensure keyboard tray is level, do not over-tighten clamps. Slide keyboard tray forward/back to desired position.
- Page 7 [ THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK]...
- Page 8 LAST UPDATED: 03/13/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
