Black Pneumatic Wall Mounted Keyboard Tray
Instruction Manual
SKU: MOUNT-KB35B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-kb35b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-KB35B
Summary of Contents for Vivo MOUNT-KB35B
- Page 1 Black Pneumatic Wall Mounted Keyboard Tray Instruction Manual SKU: MOUNT-KB35B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-kb35b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts.
-
Page 3: Package Contents
PACKAGE CONTENTS A (x1) B (x1) C (x1) D (x1) E (x1) Wall Plate Arm Extension Keyboard Bracket Keyboard Tray Set F (x1) G (x1) H (x2) I (x5) J (x1) Handle Wall Plate Cover Velcro Pad Connecting Plate S-A (x8) S-B (x4) S-C (x2) S-D (x2) -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 OPTION A: Wood Stud Installation Place Wall Plate (A) against the wall and mark drilling locations with a pencil. Use of a stud finder and Level (T-D) is highly recommended. Drill 1.2” (30mm) deep holes using a .12” (3mm) bit, then attach Wall Plate (A) to wall using M6x50mm Screws (M-A) and a Phillips screwdriver. - Page 5 STEP 2 Slide Arm Extension (B) onto Wall Plate (A). Secure using M6x25mm Spring Screw (S-D) and Cap (H) with a Phillips screwdriver. Place Arm (C) onto Arm Extension (B). Secure using M6x25mm Spring Screw (S-D), Cap (H), and a Phillips screwdriver.
- Page 6 STEP 3 The Keyboard Bracket (D) features a tilt adjustment allowing you to use the full tilt range or limit the range, with a Tilt Screw (D1) under the bracket. Take note of the two positions below and then use 3mm Allen Wrench (T-A) to adjust the Tilt Screw (D1) so that it’s in the limited range setting.
- Page 7 STEP 4 Assemble Keyboard Tray Set (E) to Keyboard Bracket (D) and Connecting Plate (J) using M5x10mm Screws (S-A) and a Phillips Screwdriver. NOTE: Ensure the lip on Keyboard Tray Set (E) is facing up in the back and the handle mounting holes are in the front.
- Page 8 STEP 6 Attach Keyboard Bracket (D) to Arm (C) using M6x16mm Screws (S-C), M6 Washer (S-E), and 4mm Allen Wrench (T-B). STEP 7 Attach the Lever (C1) from Arm (C) to Keyboard Tray (E) using M4x6mm Screws (S-B), M4 Washers (S-F), and a Phillips screwdriver.
- Page 9 STEP 8 To set the tilt range, adjust the Tilt Screw (D1) on Keyboard Bracket (D) using 3mm Allen Wrench (T-A). When the Screw is protruding out, the keyboard tray has a limited range of tilt. The tray has full range of motion when the Screw is fully recessed into the Bracket.
- Page 10 STEP 9 Use 3mm Allen Wrench (T-A) to adjust the arm swivel points. Press and hold the Lever (C1) to adjust the height of the keyboard. Remove protective film from Velcro Pads (I) and apply to top of Keyboard Tray (E) to keep keyboard from slipping.
- Page 11 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 12 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
