- Page 1 Single Clamp Rotating Keyboard Tray SKU: MOUNT-KB04CB Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-kb04cb...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 Package Contents A (x1) B (x1) C (x1) Keyboard Tray Connecting Clamp Plate Brace D (x1) E (x1) F (x2) Clamp Sticker Plastic Bushing G (x1) Swivel Included Hardware & Tools S-A (x4) S-B (x10) T-A (x1) T-B (x1) M8x12mm M5x12mm 3mm Allen Wrench 4mm Allen Wrench...
-
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Assemble Keyboard Tray (A) together using Connecting Plate (B) and M5x12mm Screws (S-B). Tighten screws using a Phillips screwdriver. STEP 2 Attach Clamp (D) to the Connecting Plate (B) using Plastic Bushings (F) and Swivel Cap (G) as shown. - Page 5 STEP 3 Remove adhesive backing from Sticker (E) and apply to Clamp Brace (C) as shown. Choose your set placement based on Fig 1. Secure Clamp Brace (C) to the Clamp (D) using M8x12mm Screws (S-A) and 4mm Allen Wrench (T-B). Fig 1.
- Page 6 STEP 4 Clamp the assembly onto your desktop. Tighten Clamp (D) by turning the Internal Screw using 4mm Allen Wrench (T-B). Secure by tightening the Set Screw on the Swivel Cap (G) with 3mm Allen Wrench (T-A). CAUTION The Set Screw on the Swivel Cap MUST BE TIGHTENED to Screw prevent the Swivel Cap from...
- Page 7 STEP 5 Adjust as desired. 360° Place your accessories onto the Keyboard Tray (A).
- Page 8 LAST UPDATED: 7/22/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
