  • Page 1 Clamp-on Tilting Keyboard Tray with Height Adjustment MOUNT-KB05HT Assembly Manual...
  • Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
  • Page 3: Package Contents

    Package Contents A (x1) B (x2) C (x2) Keyboard Tray Tilting Bracket Clamp D (x2) E (x2) F (x1) G (x1) Support Bracket Keyboard Stop Wrist Pad Included Hardware & Tools S-A (x8) S-C (x6) S-D (x5) S-B (x8) M4x7mm Screw M5x12mm Round M5x9mm Flat Head M5x12mm Flat...
  • Page 4: Assembly Steps

    Assembly Steps STEP 1 (A) upside down and install Keyboard Stop (F) into predrilled holes using Flip Keyboard Tray M5x12mm Flat Head Screws (S-D) and a Phillips screwdriver.
  • Page 5 STEP 2 Secure Tilting Bracket Set to the outer edges of Keyboard Tray using M5x12mm Round Head (S-B) Screws and a Phillips screwdriver. The Tilting Brackets (B) should protrude from the back of the Keyboard Tray (A). Back (Bottom View) Front...
  • Page 6 STEP 3 Choosing Assembly Method Tray features two extension options based on the desired extension distance. Standard Extended Standard Extended Tray will be flush with desktop edge. Tray will be able to extend an additional 1.2” (30mm) when in use, but won’t be flush with desktop edge.
  • Page 7 STEP 3 - Cont’d Assemble Support Brackets (D) to Tilting Bracket Set (B) in the desired position using M4x7mm Screws (S-A) and a Phillips screwdriver. Ensure Inset Holes are Inset facing outwards. Holes...
  • Page 8: Height Settings

    STEP 4 Assemble Clamps (C) to Support Brackets (D) at the desired height using M5x8mm Screws (S-C) and a Phillips screwdriver. 5 Height Settings The Support Brackets (D) offers five height settings. Choose the setting that best fits your needs, ensuring the same setting is used for both Support Brackets. Lowest Setting Less leg room Highest Setting...
  • Page 9 STEP 5 Place the assembled keyboard mount on the edge of desk, then slide Pads (E) on the underside of each Clamp (C). Tighten Clamps to secure to desktop. Remove adhesive backing from Wrist Pad (G) and apply to keyboard tray where desired. To prevent an uneven work space, do not over-tighten the Clamps.
  • Page 10 Adjustments To adjust the tilt angle of the tray, remove the Thumbscrews (B1) from both Tilting Brackets (B). Adjust the angle of the tray to your desired position and reinstall Thumbscrews. Clamp Does Not Fit Desktop? The Clamps (C) are pre-assembled for compatibility with desktops 0-2.56” (0-65mm) thick.
  • Page 11 Assembly Complete Place accessories onto the keyboard tray. The tray can be pulled out or stowed away as needed.
  • Page 12 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
