Clamp-on Height Adjustable Keyboard Tray
with Drawer
Instruction Manual
SKU: MOUNT-KB05HB-DR
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-kb05hb-dr
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-KB05HB-DR
Summary of Contents for Vivo MOUNT-KB05HB-DR
- Page 1 Clamp-on Height Adjustable Keyboard Tray with Drawer Instruction Manual SKU: MOUNT-KB05HB-DR Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-kb05hb-dr GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Assemble Slider Brackets (B) to the Support Brackets (D) using M4x7mm Screws (S-A), making sure the countersunk holes on Support Brackets (D) are facing outward, as shown below. Tighten with a Phillips screwdriver. NOTE: Countersunk holes should be facing outward. - Page 4 STEP 2 Assemble Slider Brackets (B) to underside of Keyboard Tray (A) using M5x12mm Round Head Screws (S-B), and tighten with a Phillips screwdriver. Assemble Keyboard Tray Stop (F) to Keyboard Tray (A) using M5x12mm Flat Head Screws (S-D), and tighten with a Phillips screwdriver.
- Page 5 STEP 3 Assemble Clamps (C) to Support Brackets (D) at desired height using M5x8mm Screws (S-C). Tighten with a Phillips screwdriver. 5 Height Settings Highest Lowest Setting Setting Adjusting Clamp for Greater Desktop Thickness Clamps are pre-assembled for compatibility with desktops 0-65mm (2.56”) thick.
- Page 6 STEP 4 Place assembled keyboard mount on edge of desk, then slide Pads (E) on the underside of each Clamp (C). Tighten clamps to secure to desktop NOTE: To ensure keyboard tray is level, do not over-tighten clamps. Slide keyboard tray forward/back to desired position. Keyboard tray now ready for use.
- Page 7 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
