White Clamp-on Keyboard Tray
Instruction Manual
SKU: MOUNT-KB05W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-kb05w
help@vivo-us.com
www.vivo-us.com
1-800-371-5654

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOUNT-KB05W and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo MOUNT-KB05W

  • Page 1 White Clamp-on Keyboard Tray Instruction Manual SKU: MOUNT-KB05W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-kb05w help@vivo-us.com www.vivo-us.com 1-800-371-5654...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY . 11lbs Failure to do so may result in serious injury. (4.99kg) Phillips Scissors Screwdriver ASSEMBLY STEPS STEP 1 Cut ties from keyboard brackets (K). Screw knobs (F) into keyboard brackets (K). Assemble washers (D), clamp plates (G) and M5x12 bolts (E) into top of knobs.
  • Page 4 STEP 2 Apply square pads (H) to underside of clamp brackets (J). STEP 3 Assemble clamp brackets (J) to keyboard brackets (K) using M8x12 bolts (B) and tighten with 5mm Allen key (C).
  • Page 5 STEP 4 Apply oval pads (I) to top of clamp plates. STEP 5 Assemble keyboard brackets to keyboard tray (L) using M5x12 bolts (A), making sure the cable organizer is facing towards the back.
  • Page 6 STEP 6 Place assembled keyboard mount on edge of desk and tighten clamps. NOTE: To ensure keyboard tray (L) is level, do not over-tighten clamps.
  • Page 7 STEP 7 Slide keyboard tray (L) forward/back to desired position.
  • Page 8 Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
