Cypress Semiconductor CY7C1471BV25 Specification Sheet

Features
■ No Bus Latency™ (NoBL™) architecture eliminates dead
cycles between write and read cycles
■ Supports up to 133 MHz bus operations with zero wait states
■ Data transfers on every clock
■ Pin compatible and functionally equivalent to ZBT™ devices
■ Internally self timed output buffer control to eliminate the need
to use OE
■ Registered inputs for flow through operation
■ Byte Write capability
■ 2.5V IO supply (V )
DDQ
■
Fast clock-to-output times
❐ 6.5 ns (for 133-MHz device)
■
Clock Enable (CEN) pin to enable clock and suspend operation
■ Synchronous self timed writes
■ Asynchronous Output Enable (OE)
■ CY7C1471BV25, CY7C1473BV25 available in
JEDEC-standard Pb-free 100-pin TQFP, Pb-free and
non-Pb-free 165-ball FBGA package. CY7C1475BV25
available in Pb-free and non-Pb-free 209-ball FBGA package.
■ Three Chip Enables (CE , CE
1
expansion.
■ Automatic power down feature available using ZZ mode or CE
deselect.
■ IEEE 1149.1 JTAG Boundary Scan compatible
■ Burst Capability - linear or interleaved burst order
■ Low standby power
Selection Guide
Description
Maximum Access Time
Maximum Operating Current
Maximum CMOS Standby Current
Cypress Semiconductor Corporation
Document #: 001-15013 Rev. *E
Flow-Through SRAM with NoBL™ Architecture
, CE ) for simple depth
2 3
133 MHz
6.5
305
120
• 198 Champion Court
CY7C1473BV25, CY7C1475BV25
72-Mbit (2M x 36/4M x 18/1M x 72)

Functional Description

The CY7C1471BV25, CY7C1473BV25, and CY7C1475BV25
are 2.5V, 2M x 36/4M x 18/1M x 72 synchronous flow through
burst SRAMs designed specifically to support unlimited true
back-to-back read or write operations without the insertion of
wait states. The CY7C1471BV25, CY7C1473BV25, and
CY7C1475BV25 are equipped with the advanced No Bus
Latency (NoBL) logic required to enable consecutive read or
write operations with data transferred on every clock cycle. This
feature dramatically improves the throughput of data through the
SRAM, especially in systems that require frequent write-read
transitions.
All synchronous inputs pass through input registers controlled by
the rising edge of the clock. The clock input is qualified by the
Clock Enable (CEN) signal, which when deasserted suspends
operation and extends the previous clock cycle. Maximum
access delay from the clock rise is 6.5 ns (133-MHz device).
Write operations are controlled by two or four Byte Write Select
(BW ) and a Write Enable (WE) input. All writes are conducted
X
with on-chip synchronous self timed write circuitry.
Three synchronous Chip Enables (CE
asynchronous Output Enable (OE) provide easy bank selection
and output tri-state control. To avoid bus contention, the output
drivers are synchronously tri-stated during the data portion of a
write sequence.
For best practice recommendations, refer to the Cypress appli-
cation note AN1064, SRAM System Guidelines.
100 MHz
8.5
275
120
,
• San Jose CA 95134-1709
CY7C1471BV25
, CE , CE ) and an
1 2 3
Unit
ns
mA
mA
• 408-943-2600
Revised February 29, 2008
