Features
■ Separate independent read and write data ports
❐
Supports concurrent transactions
■ 300 MHz clock for high bandwidth
■
4-word burst for reducing address bus frequency
■ Double Data Rate (DDR) interfaces on both read and write ports
(data transferred at 600 MHz) at 300 MHz
■ Two input clocks (K and K) for precise DDR timing
❐
SRAM uses rising edges only
■ Two input clocks for output data (C and C) to minimize clock
skew and flight time mismatches
■ Echo clocks (CQ and CQ) simplify data capture in high-speed
systems
■ Single multiplexed address input bus latches address inputs
for both read and write ports
■ Separate port selects for depth expansion
■
Synchronous internally self-timed writes
■
QDR-II operates with 1.5 cycle read latency when DLL is
enabled
■ Operates as a QDR-I device with 1 cycle read latency in DLL
off mode
■ Available in x 8, x 9, x 18, and x 36 configurations
■ Full data coherency, providing most current data
■ Core V = 1.8 (±0.1V); IO V
DD
■ Available in 165-Ball FBGA package (15 x 17 x 1.4 mm)
■
Offered in both Pb-free and non Pb-free packages
■ Variable drive HSTL output buffers
■ JTAG 1149.1 compatible test access port
■ Delay Lock Loop (DLL) for accurate data placement
Selection Guide
Description
Maximum Operating Frequency
Maximum Operating Current
Cypress Semiconductor Corporation
Document Number: 001-07037 Rev. *D
= 1.4V to V
DDQ DD
300 MHz 278 MHz
300
x8 885
x9 900
x18 940
x36 1040
• 198 Champion Court
CY7C1411BV18, CY7C1426BV18
CY7C1413BV18, CY7C1415BV18
36-Mbit QDR™-II SRAM 4-Word
Configurations
CY7C1411BV18 – 4M x 8
CY7C1426BV18 – 4M x 9
CY7C1413BV18 – 2M x 18
CY7C1415BV18 – 1M x 36

Functional Description

The CY7C1411BV18, CY7C1426BV18, CY7C1413BV18, and
CY7C1415BV18 are 1.8V Synchronous Pipelined SRAMs,
equipped with QDR™-II architecture. QDR-II architecture
consists of two separate ports to access the memory array. The
read port has dedicated data outputs to support the read opera-
tions and the write port has dedicated data inputs to support the
write operations. QDR-II architecture has separate data inputs
and data outputs to completely eliminate the need to
"turn-around" the data bus required with common IO devices.
Access to each port is through a common address bus.
Addresses for read and write addresses are latched on alternate
rising edges of the input (K) clock. Accesses to the QDR-II read
and write ports are completely independent of one another. To
maximize data throughput, read and write ports are equipped
with DDR interfaces. Each address location is associated with
four 8-bit words
(CY7C1426BV18), 18-bit words (CY7C1413BV18), or 36-bit
words (CY7C1415BV18) that burst sequentially into or out of the
device. Because data can be transferred into and out of the
device on every rising edge of both input clocks (K and K and C
and C), memory bandwidth is maximized while simplifying
system design by eliminating bus "turn-arounds."
Depth expansion is accomplished with port selects, which
enables each port to operate independently.
All synchronous inputs pass through input registers controlled by
the K or K input clocks. All data outputs pass through output
registers controlled by the C or C (or K or K in a single clock
domain) input clocks. Writes are conducted with on chip
synchronous self-timed write circuitry.
250 MHz 200 MHz
278 250
815 745
830 760
865 790
950 870
,
• San Jose CA 95134-1709
Burst Architecture
(CY7C1411BV18), 9-bit
167 MHz
200 167
620 535
620 535
655 565
715 615
• 408-943-2600
Revised June 16, 2008
words
Unit
MHz
mA
