Cypress Semiconductor CY7C1440AV33 Specification Sheet

Features
• Supports bus operation up to 250 MHz
• Available speed grades are 250, 200 and 167 MHz
• Registered inputs and outputs for pipelined operation
• 3.3V core power supply
• 2.5V/3.3V I/O power supply
• Fast clock-to-output times
— 2.6 ns (for 250-MHz device)
• Provide high-performance 3-1-1-1 access rate
• User-selectable burst counter supporting Intel
®
Pentium interleaved or linear burst sequences
• Separate processor and controller address strobes
• Synchronous self-timed writes
• Asynchronous output enable
• Single Cycle Chip Deselect
• CY7C1440AV33, CY7C1442AV33 available in lead-free
100-pin TQFP package, lead-free and non-lead-free
165-ball FBGA package. CY7C1446AV33 available in
lead-free and non-lead-free 209-ball FBGA package
• Also available in lead-free packages
• IEEE 1149.1 JTAG-Compatible Boundary Scan
• "ZZ" Sleep Mode Option
Selection Guide
Maximum Access Time
Maximum Operating Current
Maximum CMOS Standby Current
Note:
1. For best-practices recommendations, please refer to the Cypress application note System Design Guidelines on www.cypress.com.
Cypress Semiconductor Corporation
Document #: 38-05383 Rev. *E
36-Mbit (1M x 36/2M x 18/512K x 72)
Functional Description
The CY7C1440AV33/CY7C1442AV33/CY7C1446AV33 SRAM
integrates 1M x 36/2M x 18 and 512K x 72 SRAM cells with
advanced synchronous peripheral circuitry and a two-bit
counter for internal burst operation. All synchronous inputs are
gated by registers controlled by a positive-edge-triggered
Clock Input (CLK). The synchronous inputs include all
addresses, all data inputs, address-pipelining Chip Enable
(CE ), depth-expansion Chip Enables (CE
1
Control inputs (ADSC, ADSP, and ADV), Write Enables (BW
and BWE), and Global Write (GW). Asynchronous inputs
include the Output Enable (OE) and the ZZ pin.
®
Addresses and chip enables are registered at rising edge of
clock when either Address Strobe Processor (ADSP) or
Address Strobe Controller (ADSC) are active. Subsequent
burst addresses can be internally generated as controlled by
the Advance pin (ADV).
Address, data inputs, and write controls are registered on-chip
to initiate a self-timed Write cycle.This part supports Byte Write
operations (see Pin Descriptions and Truth Table for further
details). Write cycles can be one to two or four bytes wide as
controlled by the byte write control inputs. GW when active
LOW causes all bytes to be written.
The
operates from a +3.3V core power supply while all outputs may
operate with either a +2.5 or +3.3V supply. All inputs and
outputs are JEDEC-standard JESD8-5-compatible.
250 MHz
2.6
475
120
• 198 Champion Court •
CY7C1440AV33
CY7C1442AV33
CY7C1446AV33
Pipelined Sync SRAM
[1]
CY7C1440AV33/CY7C1442AV33/CY7C1446AV33
200 MHz 167 MHz
3.2 3.4
425 375
120 120
,
San Jose CA 95134-1709
Revised June 23, 2006
and CE ), Burst
2 3
X
Unit
ns
mA
mA
• 408-943-2600
