SSV Works MAVR-PHZ4ATD Manual page 7

G. Mount the brackets on the Mav R subwoofer enclosure using (4)
M6x12mm hex head bolts and washers.
I. Align the front screw holes and use (2) M6x16mm hex head bolts
and washer to secure the enclosure.
MAVERICK R POWER AND SPEAKER WIRING
A. Remove the battery cover behind the driver seat.
G
H. Slide the Mav R subwoofer enclosure under the front seat rail
mounts and insert the brackets to the rear seat rail studs.
I
J. Installation shown is manual was done under the driver seat,
installation under the passenger seat will have the same procedure.
A
B. Disconnect negative battery terminal.
H
J
B
7
