- Page 1 4K KVM Extender over Fiber 4KIP500F-KVM User Manual...
-
Page 2: Table Of Contents
Table of Contents Introduction ......................2 Overview ..........................2 Features ............................ 2 Package Contents ........................2 Panel ............................3 Transmitter ........................3 Receiver ........................... 4 Installation and Application ................5 Brackets Installation ......................5 Application ..........................5 Specification ......................7 Using DIP Switch to Perform Routing .............. -
Page 3: Introduction
Introduction Introduction Overview This product is a 4K KVM Extender set. It extends 4K video and USB 2.0 signals along long distance with zero latency, ideal for the professional A/V scenarios where UHD displays and real-time interactions are required. Features Transmits 4K video along unlimited distance over 1G network via 1Gbps ... -
Page 4: Panel
Introduction Panel Transmitter Front Panel Name Description Connect to a receiver or a switch for media stream output via a duplex Optical OM4 multimode fiber optic cable. • On: The transmitter is paired with a receiver successfully. Link LED • Off: The transmitter is not paired with a receiver. -
Page 5: Receiver
Introduction Name Description • If you change the positions of the DIP switches on the transmitter and/or the receiver, you must restart the device for setting changes to take effect. Receiver Front Panel Name Description Connect to USB devices e.g. a keyboard, a mouse and a USB flash drive, USB Device etc. -
Page 6: Installation And Application
Installation and Application Name Description information, see “Using DIP Switch to Perform Routing”. Note: By default, each individual switch is in the up position. If you change the positions of the DIP switches on the transmitter and/or the receiver, you must restart the device for setting changes to take effect. - Page 7 Installation and Application Udisk HDMI Receiver Transmitter HDMI Fiber Optic Cable Display Keyboard Mouse Application 2: Connect Transmitter and Receiver through an Ethernet Switch The transmitter and receiver could be connected through one or more network switches. With the 4-Pin DIP switch built-in, up to 16 sets of transmitter and receiver in the same network without specific VLAN settings could extend HDMI and USB signals to an unlimited distance.
-
Page 8: Specification
Specification Udisk HDMI Receiver 1 Transmitter 1 Ethernet Switch USB Camera HDMI Transmitter 2 Receiver 2 Udisk HDMI Transmitter 16 Receiver 16 Specification Transmitter Technical 1 x HDMI IN (19-pin female HDMI Type-A), 1 x USB HOST (female Input/Output USB Type-B), 1 x 4-Pin DIP Switch, 1 x DC 12V connector, 1 x Optical (1Gbps MM SFP module) Input Signal Type HDMI 1.4b... - Page 9 Specification Technical Fiber Optic Connector LC to LC Type Fiber Optic Type Duplex Multi-mode 850nm OM4 Fiber Maximum Transmission 550m/1804ft Distance General Operating Temperature 0 to 45°C (32 to 113 °F) Storage Temperature -20 to 70°C (-4 to 158 °F) Humidity 10% to 90%, non-condensing Human Body Model:...
-
Page 10: Using Dip Switch To Perform Routing
Using DIP Switch to Perform Routing Technical Fiber Optic Type Duplex Multi-mode 850nm OM4 Fiber Transmission Distance 550m/1804ft USB Consumption Recommended no more than 0.5A per USB port General Operating Temperature 0 to 45°C (32 to 113 °F) Storage Temperature -20 to 70°C (-4 to 158 °F) Humidity 10% to 90%, non-condensing... -
Page 11: Warranty
Products are backed by a limited 1-year parts and labor warranty. For the following cases AV Access shall charge for the service(s) claimed for the product if the product is still remediable and the warranty card becomes unenforceable or inapplicable.
