- Page 1 4KEX100-KVM 4K HDBaseT Extender 100m with USB2.0 User Manual...
- Page 3 AV Access Technology Limited assumes no responsibility for any inaccuracies that may be contained in this document. AV Access Technology Limited also makes no commitment to update or to keep current the information contained in this document.
- Page 4 Important Safety Instructions Do not expose this apparatus to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the apparatus. Do not install or place this unit in a bookcase, built-in cabinet, or in another ...
-
Page 5: Table Of Contents
Table of Contents Introduction ......................2 Overview ..........................2 Features ............................ 2 Package Contents ........................3 Panel ............................4 Transmitter ........................4 Receiver ........................... 6 Installation and Application................. 8 Installation ..........................8 Application ..........................8 EDID Management ..................... 10 Specification ....................... 11 Transmitter ........................ -
Page 6: Introduction
Introduction Introduction Overview 4KEX100-KVM is a 100m 4K HDBaseT 2.0 Extender which offers the distribution of uncompressed 4K@60Hz UHD video, Analog Stereo, power, RS232 and USB 2.0 up to 100m/330ft over a single Cat6 or above cable. With USB 2.0 pass-through and USB Host connector in TX, and USB Device... -
Page 7: Package Contents
Does not support HDCP Package Contents Before you start the installation of the product, please check the package contents: Transmitter 4KEX100-KVM x 1 Receiver 4KEX100-KVM x 1 12 VDC 2A Power Supply x 1 Phoenix Male Connector (3.5 mm, 3 pins) x 2 ... -
Page 8: Panel
Introduction Panel Transmitter Front Panel Name Description ON: The transmitter is powered on. Power LED OFF: The transmitter is powered off. Flashing Slowly: Status LED The transmitter is working properly. OFF: The transmitter is not working properly. ON: HDBT Link is normal Link LED OFF: No HDBT Link www.avaccess.com... - Page 9 Introduction Rear Panel Name Description 12V DC power input, threaded port for standard or DC 12V locking connection HDBT OUT Connects to HDBT IN port of receiver RS232 RS232 pass through HDMI IN Connects to an HDMI source Input: connects to audio devices AUDIO Output: connects to audio devices EDID...
-
Page 10: Receiver
Introduction Receiver Front Panel Name Description ON: The receiver is powered on. Power LED OFF: The receiver is powered off. Flashing Slowly: Status LED The receiver is working properly. OFF: The receiver is not working properly. ON: HDBT Link is normal Link LED OFF: No HDBT Link www.avaccess.com... - Page 11 Introduction Rear Panel Name Description 12V DC power input, threaded port for standard or DC 12V locking connection HDBT IN Connects to HDBT OUT port of transmitter RS232 RS232 pass through HDMI OUT Connects to an HDMI Sink Input: connects to audio devices AUDIO Output: connects to audio devices Connects to USB device such as keyboard, mouse, USB...
-
Page 12: Installation And Application
Installation and Application Installation and Application Installation Note: Before installation, please ensure the device is disconnected from the power source. Steps to install the device in a suitable location: Attach the installation bracket to the enclosure using the screws provided in the package separately. - Page 13 Installation and Application Power supply Connect the Connect the power Connect USB Host Connect Audio HDMI source Note: When transmitter port to the PC Input source is powered on, receiver is adapter free. DC 12V HDMI In Audio In EDID USB Host HDBT Out RS232...
-
Page 14: Edid Management
EDID Management EDID Management Please use the DIP Switch for EDID management: DIP Switch Position 1 Position 2 Position 3 EDID Copy (Default) DOWN DOWN 3840 x 2160P@30Hz 2CH DOWN RESERVED 1920 x 1080P@60Hz 2CH DOWN 1920 x 1200@60Hz 2CH Note: If EDID copy failed, it will use 1080p/2ch as EDID for input. -
Page 15: Specification
Specification Specification Transmitter Video Input Signal Type HDMI 1.4 with 4K 4096x2160@24/25/30/50/60Hz, Input Resolution Support 3840x2160@24/25/30/50/60Hz, 1080P, 1080I, 720P, 576p, 576i, 480p Maximum Pixel Clock 297MHz Output Signal Type HDBT 2.0 4096x2160@24/25/30/50/60Hz, Output Resolution Support 3840x2160@24/25/30/50/60Hz, 1080P, 1080I, 720P, 576p, 576i, 480p Audio Audio input 3.5mm Mini jack, stereo... -
Page 16: Receiver
Specification Power cord: 2 kV Power Supply DC 12V 2A Power Consumption ≤12 W (pair) (Maximum) Device Dimensions 210mm x 25mm x 90.2mm / (W x H x D) 8.27’’ x 0.98’’ x 3.55’’ Product Weight 0.44kg/0.97lb Receiver Video Input Signal Type HDBT 2.0 4096x2160@24/25/30/50/60Hz, Input Resolution Support... - Page 17 210mm x 25mm x 90.2mm / (W x H x D) 8.27’’ x 0.98’’ x 3.55’’ Product Weight 0.46kg/1.01lb Transmission Distance Note: AV Access recommends use of straight-through Category cables wired to T568B standard. Cable Type Range Supported Video Cat 5e...
-
Page 18: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide. - Page 20 AV Access Technology Limited V1.0.3...
