Product Diagram (I43-SERIAL-ETHERNET)
Front View
2
Component
1
Status LED
Wall Mounting Bracket
2
Holes
3
DB-9 Serial Ports
Serial Communication LED
4
Indicators
(Not Labelled)
DIN Rail Mounting Holes
5
(Not Shown)
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
1
3
• Refer to LED Chart
• Used to secure the Serial Device
Server to a Wall or Other Surface
using appropriate Mounting Hardware
• Connect an RS-232 Serial Device
• Below each DB-9 Port
• Refer to LED Chart
• Four Holes on the bottom of the Serial
Device Server
• Used to secure the included DIN Rail
Mounting Kit to the Serial Device
Server
6
2
Function
