Product Diagram (I23-SERIAL-ETHERNET)
Front View
2
Component
1
Status LED
Wall Mounting Bracket
2
Holes
Serial Communication LED
3
Indicators
4
DB-9 Serial Ports
DIN Rail Mounting Holes
5
(Not Shown)
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
1
3
• Refer to LED Chart
• Used to secure the Serial Device
• Refer to LED Chart
• Connect an RS-232 Serial Device
• Four Holes on the bottom of the Serial
• Used to secure the included DIN Rail
4
3
Function
Server to a Wall or Other Surface
using appropriate Mounting Hardware
Device Server
Mounting Kit to the Serial Device
Server
4
