LED Chart
LED Name
Link/Activity LEDs
1
(RJ-45)
Serial Port LEDs
2
(DB-9)
3
Power/Status LED
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
• Steady Green: Indicates Ethernet connection
has established, but no data activity
• Blinking Green: Indicates data activity
• Off: Ethernet is not connected
• Blinking Green: Indicates serial data is being
transmitted and/or received
• Right LED: Transmit Data Indicator
• Left LED: Receive Data Indicator
• Off: No serial data is being transmitted or
received
• Steady Green: Power is On
• Off: Power is Off
• Blinking Green: Restoring to Factory
Defaults
18
LED Function
