CY7C09079V/89V/99V
CY7C09179V/89V/99V
Features
True Dual-Ported memory cells which enable simultaneous
■
access of the same memory location
6 Flow-Through and Pipelined devices
■
32K x 8/9 organizations (CY7C09079V/179V)
■
64K x 8/9 organizations (CY7C09089V/189V)
■
128K x 8/9 organizations (CY7C09099V/199V)
■
3 Modes
■
Flow-Through
■
Pipelined
■
Burst
■
Pipelined output mode on both ports enables fast 100 MHz
■
operation
0.35-micron CMOS for optimum speed and power
■
Logic Block Diagram
R/W
L
OE
L
CE
0L
CE
1L
FT/Pipe
L
[2]
I/O
–I/O
0L
7/8L
15/16/17
[3]
A
–A
0
14/15/16L
CLK
L
ADS
L
CNTEN
L
CNTRST
L
Notes
1. See page 6 for Load Conditions.
2. I/O
–I/O
for x8 devices, I/O
–I/O
0
7
0
3. A
–A
for 32K, A
–A
for 64K, and A
0
14
0
15
Cypress Semiconductor Corporation
Document #: 38-06043 Rev. *C
1
0
0/1
1
0
0/1
8/9
I/O
Control
Counter/
Address
True Dual-Ported
Register
Decode
for x9 devices.
8
–A
for 128K devices.
0
16
•
198 Champion Court
3.3V 32K/64K/128K x 8/9
Synchronous Dual-Port Static RAM
High speed clock to data access 6.5[1]/7.5[1]/9/12 ns (max.)
■
3.3V low operating power
■
Active= 115 mA (typical)
■
Standby= 10 μA (typical)
■
Fully synchronous interface for easier operation
■
Burst counters increment addresses internally
■
Shorten cycle times
■
Minimize bus noise
■
Supported in Flow-Through and Pipelined modes
■
Dual Chip Enables for easy depth expansion
■
Automatic power down
■
Commercial and Industrial temperature ranges
■
Available in 100-pin TQFP
■
Pb-free packages available
■
I/O
Control
RAM Array
•
San Jose
CY7C09079V/89V/99V
CY7C09179V/89V/99V
1
0
0/1
0
1
0/1
8/9
I/O
0R
15/16/17
A
–A
0
Counter/
Address
Register
Decode
CNTRST
,
CA 95134-1709
•
408-943-2600
Revised December 10, 2008
