Cypress Semiconductor FLEx18 CY7C0830AV Specification Sheet

Flex18 3.3v 64k/128k x 36 and 128k/256k x 18 synchronous dual-port ram

Advertisement

Quick Links

Features
True Dual-Ported Memory Cells that Allow Simultaneous
Access of the Same Memory Location
Synchronous Pipelined Operation
Family of 512 Kbit, 1 Mbit, 2 Mbit, 4 Mbit, and 9 Mbit Devices
Pipelined Output Mode Allows Fast Operation
0.18 micron CMOS for Optimum Speed and Power
High Speed Clock to Data Access
3.3V Low Power
Active as Low as 225 mA (typ)
Standby as Low as 55 mA (typ)
Mailbox Function for Message Passing
Global Master Reset
Separate Byte Enables on Both Ports
Commercial and Industrial Temperature Ranges
IEEE 1149.1 Compatible JTAG Boundary Scan
144-Ball FBGA (13 mm × 13 mm) (1.0 mm pitch)
120 TQFP (14 mm x 14 mm x 1.4 mm)
Pb-Free Packages Available
Counter Wrap Around Control
Internal Mask Register Controls Counter Wrap Around
Counter-Interrupt Flags to Indicate Wrap Around
Memory Block Retransmit Operation
Counter Readback on Address Lines
Mask Register Readback on Address Lines
Dual Chip Enables on Both Ports for Easy Depth Expansion
Table 1. Product Selection Guide
Density
(32K x 18)
Part Number
CY7C0837AV
Maximum Speed (MHz)
Maximum Access Time -
Clock to Data (ns)
Typical Operating
Current (mA)
Package
144 FBGA
Note
1. CY7C0832AV and CY7C0832BV are functionally identical.
Cypress Semiconductor Corporation
Document #: 38-06059 Rev. *S
128K/256K x 18 Synchronous Dual-Port RAM
512 Kbit
1 Mbit
(64K x 18)
CY7C0830AV
167
167
4.0
4.0
225
225
120 TQFP
144 FBGA
198 Champion Court
CY7C0837AV, CY7C0830AV
CY7C0831AV, CY7C0832AV
CY7C0832BV, CY7C0833AV
FLEx18™ 3.3V 64K/128K x 36 and

Functional Description

The FLEx18™ family includes 512 Kbit, 1 Mbit, 2 Mbit, 4 Mbit,
and 9 Mbit pipelined, synchronous, true dual port static RAMs
that are high speed, low power 3.3V CMOS. Two ports are
provided, permitting independent, simultaneous access to any
location in memory. The result of writing to the same location by
more than one port at the same time is undefined. Registers on
control, address, and data lines allow for minimal setup and hold
time.
During a Read operation, data is registered for decreased cycle
time. Each port contains a burst counter on the input address
register. After externally loading the counter with the initial
address, the counter increments the address internally (more
details to follow). The internal Write pulse width is independent
of the duration of the R/W input signal. The internal Write pulse
is self-timed to allow the shortest possible cycle times.
A HIGH on CE0 or LOW on CE1 for one clock cycle powers down
the internal circuitry to reduce the static power consumption. One
cycle with chip enables asserted is required to reactivate the
outputs.
Additional features include: readback of burst-counter internal
address value on address lines, counter-mask registers to
control the counter wrap around, counter interrupt (CNTINT)
flags, readback of mask register value on address lines,
retransmit functionality, interrupt flags for message passing,
JTAG for boundary scan, and asynchronous Master Reset
(MRST).
The CY7C0833AV device in this family has limited features. See
Address Counter and Mask Register Operations
for details.
2 Mbit
(128K x 18)
(256K x 18)
CY7C0831AV
CY7C0832AV
167
167
4.0
4.0
225
225
120 TQFP
120 TQFP
144 FBGA
144 FBGA
,
San Jose
CA 95134-1709
[16]
on page 6
4 Mbit
9 Mbit
(512K x 18)
[1]
CY7C0832BV
CY7C0833AV
133
133
4.4
4.7
225
270
120 TQFP
144 FBGA
408-943-2600
Revised March 03, 2009
[+] Feedback
