TSC PRINTRONIX AUTO ID Alpha-3R Series Service Manual page 10

Dicrect thermal mobile barcode printers
Hide thumbs Also See for PRINTRONIX AUTO ID Alpha-3R Series:
Table of Contents

Advertisement

5
Head open sensor
6
USB & RS 232 connector
7
12V DC IN
8
TPH connector
9
Paper sensor
Pin
Description
1
3.3V
2
GND
3
RESET
4
BMS
5
NPCS0
6
MOSI
7
MISO
8
SPCK
Pin
Description
1
HEAD
2
GND
Pin
Description
1
3.3V
2
BM_E
3
BM_R
4
3.3V
6
