- Page 1 Assembly and Commissioning Instructions according to Machinery Directive 2006 / 42 / EC (annex VI) LLA10 / LLA16 S12 24V DC - L ouVre DriVeS for winDowS...
- Page 2 Contents Abbreviations Target Groups Warning and Safety Symbols Intended Use 3 - 8 Safety Instructions Data sheet LLA 10 / LLA 16 S12 24V DC Explanations on the product label 9 - 10 Inspection before the installation nstallatIon step Installation prerequisite and Installation preparation nstallatIon step 11 - 12 Change of the running direction and terminals assignment...
-
Page 3: Target Group
Preliminary remark Abbreviations Warning and safety symbols in these Instructions: Index of abbreviations These abbreviations are used consistently throughout these assembly The symbols used in the instructions shall be strictly observed and have & operating instructions. Unless stated differently, all dimensions indi- the following meaning: cated in this document are in mm. -
Page 4: Intended Use
Preliminary remark Intended use Area of application / Scope of application This drive is intended for the electromotive opening and We as manufacturers are well aware of our duties and closing of windows in facade and roof areas. responsibilities regarding the development, manufactu- The main task of this product, in combination with ring and placing of safe window drives on the market and a window and a suitable external control unit, is to... -
Page 5: Preliminary Remark
Preliminary remark Hazard analysis according to DIN EN 60335-2-103 NRWG according to NRWG according to EN12101-2 with EN12101-2 without Use of the drive dual purpose for ventilation dual purpose for ventilation (1.Z.109) AUTION Natural ventilation Keep people away during closing! Installation height of drive and lower edge of casement: >... -
Page 6: Safety Instructions
Safety instructions Safety instructions It is important to follow these instruc- Installation tions for the safety of persons. These These instructions address expert and safety-conscious ARNING instructions shall be kept in a safe place electricians and / or qualifi ed personnel knowledgeable in for the entire service life of the products. - Page 7 Safety instructions Crush and shear points All-pole disconnecting devices shall be instal- To avoid injuries, crushing and shear points between led in the permanent electrical installation or casement and frame must be secured against entrapment external Control Unit for the drive. up to an installation height of 2,5 meters above the The mains supply lines 230 V / 400 V AC shall oor with appropriate measures.
-
Page 8: Ambient Conditions
Safety instructions Commissioning, operation and maintenance Replacement parts, fasteners and controls After the installation and after each modifi cation in the set The drive shall only be operated with control devices from up all functions shall be checked with a trial run. It shall the same manufacturer. -
Page 9: Data Sheet
Data sheet Data sheet LLA10 / LLA16 S12 24V DC ■ Application: natural ventilation, SHEV, ferralux®-NSHEV ■ Internal Intelligent Control Electronics S12 ■ Push-button for the selection of the running direction ■ Robust corrosion-resistant design ■ Easy installation by concealed holes below the oblique end caps ■... - Page 10 Data sheet Order Data Part.-No. s [mm] L [mm] L1 [mm] Version Finish PU / pcs. 520306 LLA10 60 S12 E6/C-0 520312 LLA10 120 S12 E6/C-0 520343 LLA10 200 S12 E6/C-0 520406 LLA16 60 S12 E6/C-0 520412 LLA16 120 S12 E6/C-0 520423 LLA16 200 S12...
- Page 11 Preparing assembly INSTALLATION STEP 1: Inspection before the installation Important instructions for a safe instal- The test procedure of drives may only be performed on a lation. Observe all instructions, wrong non-slip and secured mat or a test fi xture. During the test ARNING installation may result in serious injury! run the test element must not be interfered with.
-
Page 12: I Nstallation Step
Preparing assembly 2: Installation prerequisite and Installation preparation nstallatIon step Maximum pushing force The following conditions must be fulfilled for the instal- lation of the drives so they can be properly assembled with • Maximum pushing force / pullout force on the LLA 10: other parts and constructed to a complete machine at the 1000 N. - Page 13 Push-button and terminals connection 3: Change of the running direction and terminal assignment nstallatIon step in the louvre drive LLA 10 / LLA 16 „ Install the enclosed connection cable (3 x 0.5 mm²) with The push-button in the louvre drive LLA 10 / LLA 16 ...
- Page 14 Hole layouts and Mounting dimension 4: Mounting louvre drive nstallatIon step „ Determine fastenings. „ Produce drill holes with appropriate cross-section. (For the mounting dimensions please refer to the LLA 10 below-mentioned hole layout drawings or project- LLA 16 specific documents and drawings). Carefully clear away drilling swarfs to prevent seals from being damaged.
-
Page 15: Start Configuration
Customized coupling adapter / Learning process Customized coupling adapter It is possible to customise the followers (coupling ad- The coupling adapter are made from polyamide (PA6) as apter) which transfer the drive power to the housing. standard and have a cutout of ø13,3 x 22,5 x 8 mm. Please contact our service department. -
Page 16: Cable Routing
Cable routing 6: Cable routing on the louvre window nstallatIon step „ Route cable on the frame from the louvre window. Cable must be protected against damage (shearing-off, kinking, splitting). Cable duct glued on cable duct glued on (in addition secured with countersunk screws against breaking away) louvre window... - Page 17 Electric connection 7: Electric connetction nstallatIon step Direction of travel Polarity reversal Make sure when establishing the connection OPEN that there is no voltage at the terminals! Unused wires must be safely insulated! CLOSE Connection assignment Wire colour coding Wire colour coding DIN IEC 757 blake white...
-
Page 18: Electric Connection
Electric connection Electric connection Configuration Interface Cable junction box (for renewal) Order number: 513344 Order number: 524178 Application: Application: to extend a drive cable Hardware interface for parameterisation of drives with the A software Rated voltage: umüLLer umüLLer only for low voltage DCT. -
Page 19: Safety Test
Electric connection / Safety check snf test run nstallatIon step nstallatIon step Supply lines of Control Unit Safety check and Test run to the Drives Observe current regulations and guidelines regarding Check the mounted system for its safety; perform test run the “Fire behavior of building materials-circuit integrity and commissioning. -
Page 20: Maintenance And Repair
Maintenance and repair Help in case of Malfunctions, Repairs Maintenance and modification and Maintenance To ensure continuous function and safety of the drive periodic maintenan- ce by a specialist company is required at least once a year (as mandated Professional repair of a defect drive can only be performed at the by law for smoke and heat exhaust systems). -
Page 21: Disposal / Warranty
Disposal / Warranty Demounting Warranty and Customer Service The drives are demounted by reversing the steps, as for the installation. In principal apply our: The adjustments are omitted. „General Terms for the Supply of Products and Services of the German Electrical Industry (ZVEI)“. 1. - Page 22 Assembly Instruction LLA 10 / LLA 16...
- Page 23 Certifi cate and Declaration Note: of Conformity The proof of the application of a quality management system is for company: We declare under our sole responsibility that the product GmbH described under "Data sheet" is in conformity with the UMÜlleR UMatIC according to the certifi cation basis DIN EN 9001 as well following directives:...
- Page 24 9000021801_V1.1_KW15.2024...
