Data Memory Access Times

EEPROM Data Memory

EEPROM Read/Write Access
ATmega32(L)
18
This section describes the general access timing concepts for internal memory access.
The internal data SRAM access is performed in two clk
10.
Figure 10. On-chip Data SRAM Access Cycles
clk
CPU
Address
Compute Address
Data
WR
Data
RD
The ATmega32 contains 1024 bytes of data EEPROM memory. It is organized as a sep-
arate data space, in which single bytes can be read and written. The EEPROM has an
endurance of at least 100,000 write/erase cycles. The access between the EEPROM
and the CPU is described in the following, specifying the EEPROM Address Registers,
the EEPROM Data Register, and the EEPROM Control Register.
"Memory Programming" on page 256 contains a detailed description on EEPROM Pro-
gramming in SPI, JTAG, or Parallell Programming mode.
The EEPROM Access Registers are accessible in the I/O space.
The write access time for the EEPROM is given in Table 1. A self-timing function, how-
ever, lets the user software detect when the next byte can be written. If the user code
contains instructions that write the EEPROM, some precautions must be taken. In
heavily filtered power supplies, V
causes the device for some period of time to run at a voltage lower than specified as
minimum for the clock frequency used. See "Preventing EEPROM Corruption" on page
22 for details on how to avoid problems in these situations.
In order to prevent unintentional EEPROM writes, a specific write procedure must be fol-
lowed. Refer to the description of the EEPROM Control Register for details on this.
When the EEPROM is read, the CPU is halted for four clock cycles before the next
instruction is executed. When the EEPROM is written, the CPU is halted for two clock
cycles before the next instruction is executed.
T1 T2
Address Valid
Memory Access Instruction
is likely to rise or fall slowly on Power-up/down. This
CC
cycles as described in Figure
CPU
T3
Next Instruction
