Technical Specifications - formlabs Fuse Blast Manual

2.2

Technical specifications

Parameter
Powder recovery station
3D printing technology
Printer compatibility
Minimum dimensions for convenient
access (W × D × H)
Product dimensions (W × D × H)
Product weight
Tumbling basket dimensions
Internal work area (W x D x H)
Accessible work area (W x D x H)
Hopper capacity
Operating environment
Air handling
Power requirements
Overvoltage category
Compressed air requirements
Connectivity
Wi-Fi connectivity
Ethernet connectivity
USB connectivity
Sound emission
Unit
Fuse Blast
Selective Laser Sintering (SLS)
Fuse Series SLS 3D Printers
Third-party powder bed fusion 3D printers
145 × 150 × 210 cm
57.4 × 59.6 × 82.6 in
Additional clearance of 76.2 cm (30 in) on all sides required
100 × 75 × 175 cm
39 × 29.6 × 68.7 in
Height when open: 195 cm (76.8 in)
164 kg | 360 lb (without blasting media)
Internal diameter: 450 mm (17.7 in)
Opening diameter: 345 mm (13.6 in)
Basket depth: 250 mm (9.8 in)
Basket is removable without tools.
Fits a full Fuse 1 generation build volume.
71 x 55 x 67 cm | 27.9 x 21.6 x 26.3 in
57 x 50 x 67 cm | 22.4 x 19.6 x 26.4 in (basket removed)
Media hopper capacity 8.3 L, equivalent to 13 kg of 200–300
µm glass media
Waste hopper capacity 10.6 L
10–36 ºC | 50–96.8 ºF
Elevation up to 7500 ft / 2286 meters
Negatively pressurized hood with replaceable HEPA filter
Independent venting system
EU: 230 VAC, 3 A (no dedicated circuit or vacuum required)
US: 120 VAC, 6 A (no dedicated circuit or vacuum required)
OVC II
Supply at least 10 SCFM at 90 psi / 285 SLPM at 6 bar.
Regulate pressure input between 90–120 psi / 6–8 bar.
Typically achieved by a single 4 hp compressor.
Wi-Fi: 2.4 GHz
Ethernet: 1000 Mbit
USB: 2.0
Protocol: IEEE 802.11 b/g/n
Frequency: 2.4 GHz
Supported security: WPA/WPA2
RJ-45 Ethernet (10BASE-T/100BASE-TX/1000BASE-T) LAN port
Connect with a shielded Ethernet cable (not included):
minimum Cat5, or Cat5e or Cat6 for 1000BASE-T.
USB (rev 2.0) C port with a USB A-C or C-C cable
Under normal use the machine does reach a time-weighted
average of 85 dB(A). Hearing protection is not required.
Introduction | 11
